Dual MPPT Trackers for Maximum Solar Harvest:
Equipped with 2 independent MPPT trackers (99.9% efficiency) to optimize energy capture from 2 PV strings. Adapts to partial shading or mixed orientations, boosting daily solar yield by 8–12%. Wi-Fi app provides real-time MPPT performance data.
Broad Battery Compatibility:
Works seamlessly with 48V LiFePO4, lead-acid, and lithium-ion batteries (supports 3kWh–30kWh storage). Features a 120A smart charger with customizable profiles, extending battery life to 6,000+ cycles (15+ years for LiFePO4).
Hybrid Flexibility (Grid-Tied + Off-Grid):
Operates in grid-tied mode (exports excess solar to the grid for net metering) and switches to battery backup in <5ms during outages. Ensures uninterrupted power for critical loads (HVAC, refrigerators, medical devices).
Wi-Fi Enabled Smart Energy Management:
Use the app to track solar output, battery SOC, and grid usage in real time. Set custom schedules (e.g., charge batteries during off-peak grid hours) to cut utility costs by 30–40%. Receive instant alerts for system faults.
Pure Sine Wave Output:
Generates clean 230V AC power (pure sine wave) to protect sensitive electronics (laptops, smart home devices) and ensure compatibility with all household appliances, from microwaves to air conditioners.
| Model |
SUN-10K
|
|
Battery
|
Lead-acid / Li-lon
|
|
Battery Voltage
|
40~60V
|
|
DC Input Power
|
13000W
|
|
MPPT
|
200-650V
|
|
PV Input Current
|
26+13
|
|
AC Output Power
|
10000W
|
|
Frequency and Voltage
|
50/60Hz; 230/400V
|
|
Efficiency
|
＞97% |
|
Grid Regulation
|
CEI 0-21, VDE-AR-N 4105, NRS 097, IEC 62116, IEC 61727, G99, G98,
VDE 0126-1-1, RD 1699, C10-11
|
|
Communication
|
RS485; CAN
|
|
Protection
|
IP65
|
