Product Description
585W High Power Output & Efficiency
Industry-Leading Wattage: Generates 585W of peak power, outperforming standard 400–500W panels by 17–46% in energy yield per square meter. This reduces the number of panels needed for target capacities: a 10kW system requires just 17 panels (vs. 25+ with 400W panels), cutting installation time, hardware costs, and space usage.
Premium Conversion Efficiency: Boasts a conversion efficiency of up to 23.5%, achieved through advanced PERC (Passivated Emitter and Rear Cell) technology and half-cut monocrystalline cells. This design minimizes energy loss by enhancing light absorption and reducing electrical resistance, ensuring more sunlight is converted into usable electricity.
Double Glass Construction for Unmatched Durability
Twin Tempered Glass Layers: Features two sheets of low-iron, tempered glass (front and back) instead of a traditional plastic backsheet. This eliminates degradation from UV radiation, moisture, or chemical exposure-common issues with standard panels in humid, coastal, or industrial areas.
Extreme Weather Resistance:
Hail Impact: Withstands 25mm hail stones (exceeding the 20mm industry standard), protecting cells from physical damage.
Wind & Snow Loads: Handles 140mph+ winds and 5400Pa snow loads, making it suitable for high-altitude, storm-prone, or northern regions.
Corrosion & Moisture Resistance: Impervious to salt spray, humidity, and industrial pollutants-ideal for coastal homes, island installations, or factory rooftops.
Extended Lifespan: Double glass protects cells from debris, foot traffic (during maintenance), and environmental stress, extending the panel's lifespan to 30+ years-5–10 years longer than standard panels with plastic backsheets.
Product parameter
|
Module |
570-590 Watt
|
||||||||
|
Max Power Pmax(W) |
570 | 575 | 580 | 585 | 590 | ||||
|
Max Power Voltage(Vmp/V) |
43.58 | 43.73 | 43.88 | 44.02 | 44.17 | ||||
|
Max Power Current(Imp/A) |
13.08 | 13.15 | 13.22 | 13.29 | 13.36 | ||||
|
Open Circuit Voltage(Voc/V) |
52.1 | 52.3 | 52.5 | 52.7 | 52.9 | ||||
|
Short Circuit Current(Isc/A) |
13.83 | 13.89 | 13.95 | 14.01 | 14.07 | ||||
|
Module Efficiency(%) |
22.07 | 22.26 | 22.45 | 22.65 | 22.84 | ||||
|
Power Tolerance(W) |
0 ~ + 3 %
|
||||||||
|
Operating Temperature
|
-40 °C ~ +85 °C
|
||||||||
|
Max Series Fuse Rating
|
30 A
|
||||||||
Products Overview
| Product Specification | |
| Module Size/mm |
2278×1134×30
|
| Weight/kg | 31 |
| Cell Type |
N- type Mono
|
| Junction Box | IP68 |
Factory
Global Market Reach and Customer Support
Our solar panel factory has a global market reach. We supply our products to customers in various countries and regions around the world. To ensure customer satisfaction, we provide comprehensive customer support services. Our technical team is available to offer installation guidance, troubleshooting assistance, and after-sales service. We also maintain a strong presence in international trade shows and exhibitions to showcase our latest products and technologies and build relationships with customers and partners.
Continuous Improvement Culture
In our solar panel factory, we foster a culture of continuous improvement. We encourage our employees to identify areas for enhancement in production processes, quality control, and product design. Regular performance evaluations and feedback sessions are held to drive innovation and efficiency. We also invest in new technologies and equipment based on the insights gained from our continuous improvement efforts, ensuring that our factory remains at the cutting edge of the solar panel manufacturing industry.
FAQ
What is the size of this type of solar panel?
The size can vary depending on the manufacturer and model. Commonly, the dimensions are around 2 meters in length and 1 meter in width, but this can differ. Some panels may be larger or smaller. The size affects the power output per unit area and also determines the space required for installation, whether on a rooftop or in a ground-mounted solar farm.
Can the panels be used in coastal areas?
Yes, it is suitable for coastal areas. The double-glass construction provides good resistance to salt spray and corrosion, which are common in coastal environments. However, regular inspection and maintenance are still necessary to ensure the long-term performance and durability of the panel. The salt in the air can gradually accumulate on the surface, so more frequent cleaning may be required compared to inland installations.
