Product Descriptions
Aesthetically Pleasing Design
The panel has an aesthetically pleasing design. Its sleek and uniform appearance makes it blend well with various architectural styles and surroundings. Whether installed on rooftops or in large solar farms, it presents a clean and modern look. This not only serves the purpose of generating electricity but also adds an element of visual appeal to the installation site, making it a more acceptable choice for both residential and commercial applications where aesthetics matter.
Easy Installation and Maintenance
The panel is designed for easy installation and maintenance. It usually comes with standardized mounting holes and fittings, facilitating quick and secure installation on rooftops or in ground-mounted systems. Additionally, its smooth glass surface is easy to clean. Regular cleaning to remove dust, dirt, and bird droppings can help maintain its power generation efficiency. The absence of a complex backsheet also reduces the likelihood of certain types of damage and simplifies any necessary repair work.
Products parameters
|
Module |
570-590 Watt
|
||||||||
|
Max Power Pmax(W) |
570 | 575 | 580 | 585 | 590 | ||||
|
Max Power Voltage(Vmp/V) |
43.58 | 43.73 | 43.88 | 44.02 | 44.17 | ||||
|
Max Power Current(Imp/A) |
13.08 | 13.15 | 13.22 | 13.29 | 13.36 | ||||
|
Open Circuit Voltage(Voc/V) |
52.1 | 52.3 | 52.5 | 52.7 | 52.9 | ||||
|
Short Circuit Current(Isc/A) |
13.83 | 13.89 | 13.95 | 14.01 | 14.07 | ||||
|
Module Efficiency(%) |
22.07 | 22.26 | 22.45 | 22.65 | 22.84 | ||||
|
Power Tolerance(W) |
0 ~ + 3 %
|
||||||||
|
Operating Temperature
|
-40 °C ~ +85 °C
|
||||||||
|
Max Series Fuse Rating
|
30 A
|
||||||||
Products Overview
| Product Specification | |
| Module Size |
2278×1134×30 mm
|
| Weight | 31kg |
| Cell Type |
N- type Mono
|
| Junction Box | IP68 |
| Connector | PV |
Factory
Customization Capabilities
Our solar panel factory offers customization capabilities to meet the diverse needs of our customers. Whether it's a specific size, power output, or design requirement, we can tailor our solar panels accordingly. For example, we can produce panels for small residential rooftops as well as large-scale commercial and industrial solar farms. Our engineering team works closely with customers to understand their unique requirements and develop customized solutions, providing flexibility and value-added services.
Clean and Controlled Production Environment
The production environment in our solar panel factory is maintained to be clean and controlled. The manufacturing areas are equipped with advanced air filtration systems to prevent dust and particulate matter from contaminating the sensitive components of the solar panels. Temperature and humidity are precisely regulated to create optimal conditions for the production processes, ensuring the quality and reliability of the final product. This clean and controlled environment is essential for producing high-performance solar panels.
FAQ
What is the warranty period of the panels?
The warranty period usually ranges from 25 to 30 years. During this time, the manufacturer will cover certain defects and performance issues. The warranty typically includes a guarantee on the power output, ensuring that the panel's power degradation does not exceed a certain percentage (usually around 0.5% - 0.8% per year) over the warranty period.
How does the bifacial power generation of the panel work?
The front side of the panel absorbs direct sunlight as normal. The back side is designed to capture and convert the reflected and scattered light from the ground and surrounding environment. The panel's cell structure and design allow it to generate electricity from both sides. The amount of additional power generated from the back side depends on factors like the reflectivity of the surface below the panel (e.g., snow, sand, or water has high reflectivity) and the amount of scattered light in the surrounding area.
