N-type modules with HOT 2.0 technology offer better reliability and efficiency.
Dual-sided power generation gain increases with backside exposure to light, significantly reducing LCOE.
Products Description
HOT 2.0 Technology Solar Panels
Products parameters
|
Module |
72HL4-BDV 570-590 Watt
|
||||||||
|
Maximum Power Pmax(W) |
570 | 575 | 580 | 585 | 590 | ||||
|
Maximum Power Voltage(Vmp/V) |
43.58 | 43.73 | 43.88 | 44.02 | 44.17 | ||||
|
Maximum Power Current(Imp/A) |
13.08 | 13.15 | 13.22 | 13.29 | 13.36 | ||||
|
Open Circuit Voltage(Voc/V) |
52.1 | 52.3 | 52.5 | 52.7 | 52.9 | ||||
|
Module Efficiency(%) |
22.07 | 22.26 | 22.45 | 22.65 | 22.84 | ||||
|
Power Tolerance(W) |
0 ~ + 3 %
|
||||||||
|
Operating Temperature
|
-40 °C ~ +85 °C
|
||||||||
|
Maximum System Voltage
|
1500 VDC (IEC)
|
||||||||
|
Maximum Series Fuse Rating
|
30 A
|
||||||||
Products Overview
Advantages
Good Insulation：The insulation performance of the glass is better than that of traditional backsheets, enabling the double glass panels to meet higher system voltages, thereby saving system costs for the entire power station and improving the overall performance and safety of the power generation system.
Easy to Clean：Without an aluminum frame, 590W solar double glass panels are easier to clean. Reducing the accumulation of dust on the panel surface can effectively improve power generation efficiency.
High Fire Resistance：The fire resistance level of double glass panels is upgraded from level C of ordinary crystalline silicon panels to level A, making them more suitable for use in residential areas, chemical plants, and other places where fire hazards need to be avoided.
Environmental Protection and Recyclability：Double glass panels contain fewer organic materials, are more environmentally friendly, and are easier to recycle, which is in line with the development trend of green energy and helps reduce environmental pollution.
Flexible Installation：These panels offer more flexible installation options. They can be installed using a compression block method or a back-hanging method. The back-hanging installation can avoid shading on the front of the panel, thereby increasing power generation efficiency.
FAQ
How much space do I need to install a 590W solar double glass panel?
The space required depends on the installation configuration. If you are installing them in a ground mounted system, you need to consider the panel's dimensions and the space between panels for proper sunlight access and maintenance. Typically, each panel may have dimensions of around 2 meters by 1 meter. You also need to leave some space around the edges, usually about 0.5 - 1 meter, depending on local regulations and installation requirements. For a roof mounted installation, you need to ensure that the roof can support the weight of the panels and that there is enough unshaded area to install them effectively.
