Products Description

10-12kw Hybrid Inverter

Strong Scalability

As your energy needs grow or you decide to expand your renewable energy setup, the inverter has you covered. It offers excellent scalability, allowing you to easily add more solar panels or increase battery storage capacity. With its flexible architecture and compatibility with a range of accessories, you can adapt and upgrade your system over time without major overhauls, future-proofing your investment in clean energy.

Wide Input Voltage Range

Capable of handling a wide input voltage range, the inverter can efficiently process power even under less-than-ideal solar conditions. Whether it's early morning or late afternoon when sunlight intensity is lower, or during cloudy days with fluctuating panel voltages, it can still extract maximum power from the solar array. This wide input tolerance ensures consistent energy conversion and utilization, maximizing the return on your solar investment throughout the day.

High-Frequency Switching Technology

High-frequency switching is employed in the power conversion process to reduce the size and weight of magnetic components like inductors and transformers. By rapidly switching power transistors at high frequencies, the inverter can achieve efficient energy transfer while using smaller, more compact components. This not only improves the power density of the device but also contributes to its overall portability and ease of installation.

TYPE	GES48100M200-500	GES48120M220-500
INVERTER
Rated Output Power	10000W	12000W
Max.Peak Power	15000W	18000W
Rated Output Voltage	120/240Vac(L1/L2/N/PE split phase)
Rated AC Frequency	50/60Hz
BATTERY
Battery Type	Li-ion/Lead-Acid
Rated Battery Voltage	48V
Max.MPPT Charging Current	200A
PV INPUT
Num. of MPPT Trackers	2
Max.PV Array Power	12000W
Max.Input Current	22/22A
MPPT Voltage Range	90Vdc~450Vdc
EFFICIENCY
MPPT Tracking Efficiency	99%
Max. Battery Inverter Efficiency	92%
GENERAL
Dimensions	620450132
Operating Temperature Range	-10~55℃,>45°C derated
COMMUNICATION
Embedded interfaces	RS485/USB/ Dry contact
External Modules (Optional)	Wi-Fi/GPRS

product-1000-97

hybrid inverter071

Factory

Employee Training and Development Programs

We believe in nurturing our workforce, and thus, offer comprehensive training and development programs. New hires undergo an intensive induction covering factory safety, quality protocols, and basic manufacturing skills. Seasoned employees have access to advanced courses on new technologies, lean manufacturing principles, and leadership training. In-house workshops are conducted by industry veterans, sharing insights on the latest trends in power electronics. We also encourage employees to pursue external certifications and reimburse relevant tuition fees. This investment in our people translates into a highly skilled, motivated workforce that drives our factory's success.

FAQ

Can I use it in an off-grid application?

Certainly. The inverter is well-suited for off-grid applications. In such cases, it relies solely on the energy stored in the batteries, which are charged by solar panels or other alternative power sources like generators. It can manage power distribution to meet the demands of your off-grid setup, ensuring a consistent power supply for your essential loads, whether you're in a remote cabin or a mobile home.

What is the input voltage range it can accept?

Our inverter has a wide input voltage range to accommodate various solar conditions. It can typically handle input voltages ranging from 100V to 600V DC, depending on the model. This broad tolerance allows it to efficiently convert power even during early morning, late afternoon, or cloudy days when panel voltages may fluctuate, maximizing solar energy utilization throughout the day.
