Products Description

10-12kw Hybrid Inverter

Optimized Startup Process

The inverter features an optimized startup process that minimizes power surges and inrush currents during initial activation. It gradually ramps up its power output, allowing the connected electrical system and appliances to adjust smoothly. This gentle startup not only protects your equipment from potential damage but also reduces stress on the inverter itself, contributing to its overall reliability and longevity.

Real-Time Display of Grid Synchronization Status

Stay informed about the inverter's grid synchronization status in real-time. The display panel or monitoring interface clearly indicates whether the inverter is successfully synchronized with the utility grid, if it's in the process of synchronizing, or if there are any issues preventing synchronization. This immediate feedback enables you to quickly identify and address grid connection problems, ensuring seamless operation and power transfer between your system and the grid.

Three-Dimensional (3D) Printed Prototyping

In the research and development phase, 3D printed prototypes play a crucial role. Engineers use 3D printers to quickly fabricate physical models of the inverter's enclosure and internal structures. These prototypes allow for rapid design iterations, fitment testing of components, and evaluation of thermal management strategies before moving to mass production, saving time and costs.

TYPE	GES48100M200-500	GES48120M220-500
INVERTER
Rated Output Power	10000W	12000W
Max.Peak Power	15000W	18000W
Rated Output Voltage	120/240Vac(L1/L2/N/PE split phase)
Rated AC Frequency	50/60Hz
BATTERY
Battery Type	Li-ion/Lead-Acid
Rated Battery Voltage	48V
Max.MPPT Charging Current	200A
PV INPUT
Num. of MPPT Trackers	2
Max.PV Array Power	12000W
Max.Input Current	22/22A
MPPT Voltage Range	90Vdc~450Vdc
EFFICIENCY
MPPT Tracking Efficiency	99%
Max. Battery Inverter Efficiency	92%
GENERAL
Dimensions	620450132
Operating Temperature Range	-10~55℃,>45°C derated
COMMUNICATION
Embedded interfaces	RS485/USB/ Dry contact
External Modules (Optional)	Wi-Fi/GPRS

product-1000-97

hybrid inverter071

Factory

Renewable Energy Integration Beyond the Roof

While our solar-paneled roof is a start, we're constantly exploring ways to further integrate renewable energy into our factory operations. We're piloting projects to harness wind energy with small on-site turbines, evaluating the potential of geothermal heating and cooling systems, and looking into biofuel alternatives for our forklifts and delivery vehicles. By diversifying our renewable energy sources, we aim to achieve near-zero carbon emissions and become a model of sustainable industrial production.

FAQ

Can I connect a backup generator to the inverter?

Yes, you can connect a backup generator to the inverter. It has specific ports and control features designed for seamless integration with a generator. The inverter can intelligently manage the power flow from the generator, prioritizing battery charging when solar energy is insufficient and supplying power to essential loads. This combination provides a comprehensive backup power solution, especially for extended power outages.

What is the inverter's efficiency curve like?

The inverter's efficiency curve shows its performance across different power output levels. It typically maintains a high efficiency, around 95% to 98%, over a wide range of operating conditions. However, as the power output approaches the very low or very high ends of its rated capacity, the efficiency may gradually decrease. The exact shape of the curve depends on the inverter's design and technology, but it's optimized to ensure excellent overall performance throughout normal usage.
