Hybrid inverters are the epitome of energy efficiency, merging solar power conversion with battery storage to create a robust and reliable power solution. They offer the flexibility to switch between grid-tied and off-grid modes, ensuring continuous power supply even during grid failures. These inverters are equipped with advanced features such as MPPT technology to maximize solar energy capture and intelligent energy management systems to optimize power usage and storage. With their user-friendly interfaces and easy installation, hybrid inverters are a perfect fit for homes and businesses looking to embrace renewable energy and reduce their environmental impact.
The hybrid inverter is a sophisticated device that integrates solar power generation with battery storage, providing a comprehensive energy management solution. It supports multiple operating modes, including grid-tied, off-grid, and backup power, ensuring a reliable power supply in various scenarios. The inverter's intelligent control system optimizes energy flow, prioritizing solar power and utilizing battery storage to minimize grid dependency. With advanced safety features and easy-to-use interfaces, hybrid inverters are an excellent choice for modern homes and businesses seeking energy independence and sustainability.
Hybrid inverters are designed to enhance energy efficiency by combining solar power conversion with battery storage capabilities. They offer seamless transitions between grid-tied and off-grid operations, ensuring a stable power supply regardless of grid conditions. These inverters come with advanced features such as MPPT technology to maximize solar energy capture and smart energy management algorithms to balance power usage and storage. With their compact size and easy installation, hybrid inverters are an ideal solution for residential and commercial applications aiming to reduce energy costs and enhance sustainability.
|
Model |
S6-EH3P10K02-NV-YD-L |
Battery type |
Lead acid or lithium battery |
|
Mains mode |
Max. charge current | 220A | |
|
Nominal input voltage |
380/400V |
Charge voltage range |
40 –60Vdc |
|
Frequency |
50Hz/60Hz (Auto detection) |
Solar charge |
|
|
Max. efficiency |
97.6% |
PV operate voltage range |
200Vdc~800Vdc |
|
Inverter mode |
MPPT voltage range | 200Vdc~800Vdc | |
|
Output voltage waveform |
Pure sine wave |
Max. PV input power/current |
16000W/40A |
|
Nominal output power(VA)/(W) |
10000W |
Charge current range |
220A |
|
Nominal output voltage (Vac) |
380/400V |
Certification |
|
|
Peak power |
20000VA |
EMC certification level |
NRS 097-2-1, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530 PEA\MEA, IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-3 |
|
Protection |
IP66 |
Operate temperature range |
-40 to +60℃ |
|
Battery voltage range |
40.0Vdc~60Vdc |
communicate |
RS485/CAN |
|
Mains charge |
Humidity range | 5% to 95%(Conformal coating protection) | |
Comparison Of Protection Levels
IP66 VS IP65
Dustproofcapability: Dustproof capability:
Completely dust-proof, no particles enter Completely dust-proof, no particles enter
Waterproofcapability: Waterproofcapability:
Protect against strong water column impact, twice Protect against low pressure water column impact
the water proof capacity of IPx5
Absolute advantage:
Dust-proof , IP66 can withstand strong currents, use is wider inthe environment of strong
convective weather like typhoon, rainstorm frequent have stronger adapt ability
