Industrial Solar Energy System With 215KWH Output

215kWh High-Capacity for Industrial Demands: Industrial solar energy system delivering 215kWh total storage (172kWh usable at 80% DoD) via 280Ah LiFePO4 cells and 768V architecture. Powers medium-sized factories, warehouses, or manufacturing units through peak production hours (8 AM–4 PM), supporting heavy machinery, HVAC, and industrial lighting without grid interruptions.

Products Description

The 215KWH 768V 280AH High Voltage industrial commercial energy storage solution system with battery box container

Seamless Solar-Storage Synergy:
Integrates high-efficiency solar panels (22-23% conversion rate) with 215kWh battery storage, capturing excess daytime solar energy for use during evenings, cloudy periods, or outages. Boosts renewable self-consumption from 50% (without storage) to 85%+, slashing reliance on grid electricity.

Industrial-Grade Durability:

Batteries: 280Ah LiFePO4 cells engineered for 6,000+ cycles (15+ year lifespan) at 25°C, withstanding deep discharges and vibration (IEC 60068-2-6) from factory machinery.

Solar Panels: Weatherproof mono/polycrystalline modules with anti-reflective glass, rated for 25+ years of outdoor use (resist 160mph winds and 1.5-inch hailstones).

High-Efficiency Power Conversion:
100kW bi-directional PCS (98.2% efficiency) converts DC solar/battery energy to 3-phase AC (480V/600V) for industrial grids. Supports 1C charge/discharge (215kWh in 1 hour) to handle sudden load spikes (e.g., motor startups, compressor cycles).

Cost-Saving Energy Management:

Peak Shaving: Discharges stored solar energy during high-tariff hours, reducing industrial electricity costs by 30–40% annually (saves $20,000–$50,000/year for typical factories).

Load Optimization: Aligns solar output with production schedules, ensuring high-power equipment runs during midday solar peaks to minimize grid usage.

Remote Monitoring: Cloud-based EMS tracks solar production, battery SOC, and system health, with alerts for panel degradation or battery faults to prevent unplanned downtime.

Products parameter

BATTERY PACK 1P16S
RATED VOLTAGE	51.2V
NOMINAL CAPACITY	280AH
PACK POWER	14.336KWH
WEIGHT	130KG
BATTERY SYSTEM 1P224S
RATED VOLTAGE	716.8V
NOMINAL CAPACITY	280AH
RATED CURRENT	140A
BATTERY POWER	215KWH
VOLTAGE RANGE	627.2-806.4V
MAX EFFICIENCY	≥95%
COOLING	FORCED AIR
OPTIMAL WORKING TEMPERATURE RANGE	-20°C-60°C
PROTECTION DEGREE	IP54
DIMENSION	225013001190MM
WEIGHT	2100KG
CERTIFICATES	CE, UN38.3,UL,ROHS, EMC, REACH
