Commercial Solar Energy System With 280AH Capacity

280Ah High-Capacity Core for Commercial Energy Demands: Commercial solar system powered by 280Ah large-format LiFePO4 cells, delivering robust energy storage (e.g., 215kWh in 768V configurations) to meet daily demands of retail stores, hotels, and offices. These high-capacity cells ensure stable power for peak hours (9 AM–7 PM), supporting HVAC, refrigeration, POS systems, and lighting without interruptions.

Products Description

The 215KWH 768V 280AH High Voltage industrial commercial energy storage solution system with battery box container

Long-Lasting 280Ah Cells for Sustained Performance:
280Ah LiFePO4 cells engineered for 6,000+ charge-discharge cycles (15+ year lifespan) at 25°C, retaining 80% capacity after 10 years of daily use. Their large format reduces connection points by 50% vs. smaller cells, lowering failure risks and ensuring consistent performance in busy commercial environments.

Efficient Power Conversion & Grid Synergy:
Integrated 100kW bi-directional PCS (Power Conversion System) optimized for 280Ah cell performance, boasting 98.2% efficiency. Seamlessly converts stored DC energy to 3-phase AC (400V/480V) for grid compatibility, with <5ms switching between solar, battery, and grid power-critical for avoiding downtime during outages (e.g., preserving perishables in supermarkets).

Advanced BMS for 280Ah Cell Health:
Precision Battery Management System (BMS) monitors 280Ah cells in real time, balancing voltage to ±3mV to prevent overcharging/over-discharging. Tracks temperature, current, and cell degradation, sending alerts for maintenance needs to extend lifespan. Ensures safe operation with FM-200 fire suppression and ground fault protection (NFPA 70E compliant).

Smart Energy Management for Cost Savings:
Cloud-based EMS (Energy Management System) leverages 280Ah capacity for peak shaving (cuts demand charges by 30–40% during high-tariff hours), time-of-use arbitrage (charges at off-peak rates), and solar self-consumption (stores excess PV energy). Syncs with building BMS to prioritize critical loads (security, elevators) during outages.

Products parameter

BATTERY PACK 1P16S
RATED VOLTAGE	51.2V
NOMINAL CAPACITY	280AH
PACK POWER	14.336KWH
WEIGHT	130KG
BATTERY SYSTEM 1P224S
RATED VOLTAGE	716.8V
NOMINAL CAPACITY	280AH
RATED CURRENT	140A
BATTERY POWER	215KWH
VOLTAGE RANGE	627.2-806.4V
MAX EFFICIENCY	≥95%
COOLING	FORCED AIR
OPTIMAL WORKING TEMPERATURE RANGE	-20°C-60°C
PROTECTION DEGREE	IP54
DIMENSION	225013001190MM
WEIGHT	2100KG
CERTIFICATES	CE, UN38.3,UL,ROHS, EMC, REACH
