Products Description
-
They exhibit good heat dissipation capabilities, maintaining optimal operating temperature. Efficient heat sinks and ventilation channels are incorporated into the design of solar panels. These features help to dissipate the heat generated during the energy conversion process, preventing overheating. By maintaining an optimal operating temperature, the panels can operate at their highest efficiency and have a longer lifespan.
-
These panels are made with precision engineering, ensuring accurate energy conversion. The manufacturing process involves precise alignment and calibration of solar cells, as well as the use of high-precision machinery. This attention to detail results in accurate and consistent energy conversion, minimizing energy losses and maximizing the overall performance of the panels.
Products parameters
|
Module |
WN 550-580W - 36MH | ||||||||
|
Max Power Pmax(W) |
550 | 560 | 565 | 570 | 580 | ||||
|
Max Power Voltage(Vmp/V) |
41.50 | 41.77 | 41.92 | 42.07 | 42.37 | ||||
|
Max Power Current(Imp/A) |
13.26 | 13.41 | 13.48 | 13.55 | 13.69 | ||||
|
Open Circuit Voltage(Voc/V) |
50.21 | 50.47 | 50.60 | 50.74 | 51.02 | ||||
|
Short Circuit Current(Isc/A) |
14.00 | 14.15 | 14.23 | 14.31 | 14.47 | ||||
|
Module Efficiency(%) |
21.29 | 21.68 | 21.87 | 22.07 | 22.45 | ||||
|
Power Tolerance(W) |
0 ~ + 3 %
|
||||||||
|
Operating Temperature
|
-40 °C ~ +85 °C
|
||||||||
|
Max Series Fuse Rating
|
30 A
|
||||||||
Products Overview
| Product Specification | |
| Module Size |
2278×1134×30
|
| Weight | 29kg |
| Cell Type |
N- type Mono
|
| Junction Box | IP68 |
| Connector | PV Connector |
Technique
-
The packaging of solar panels is designed to be stackable. The boxes and crates are shaped and sized in a way that allows multiple panels to be stacked on top of each other without causing damage. This stacking design optimizes the use of storage and transportation space, reducing shipping costs and making it more efficient to handle large quantities of solar panels.
-
During the manufacturing of solar panels, a process of edge isolation is carried out. This involves removing or modifying the conductive material around the edges of the silicon wafers. Edge isolation helps to prevent current leakage and improve the overall performance of the solar cells. It can be achieved through chemical etching or the deposition of insulating materials along the edges.
FAQ
How often does the panel need to be cleaned?
The panel should be cleaned at least once or twice a year. However, in areas with high levels of dust, pollen, or bird droppings, more frequent cleaning may be required. Cleaning helps to remove any dirt or debris that can block sunlight and reduce the panel's efficiency. Regular cleaning can maintain the panel's performance and ensure maximum power output.
What is the best way to clean the panel?
The best way to clean the panel is to use a soft brush or a squeegee with a mild detergent solution and water. Avoid using abrasive materials or harsh chemicals as they can scratch the panel surface. Start from the top and work your way down, rinsing thoroughly with clean water. Some panels have a self-cleaning coating, but even with this coating, occasional manual cleaning is still beneficial.
