Voltage Compatibility
The product is engineered to handle a wide voltage range, typically from 120V to 240V, making it suitable for various household appliances and electrical systems in the US. It ensures stable power output, protecting sensitive electronics from voltage fluctuations that could otherwise damage or reduce their lifespan.
Frequency Adaptation
Operating at a standard frequency of 60Hz, this inverter synchronizes precisely with the US power grid. It can also adjust its output frequency in microseconds if there are minor grid disturbances, maintaining seamless power supply to connected devices. This feature is crucial for appliances like clocks, motors, and audio equipment that rely on a consistent frequency.
Inverter Circuit Board Assembly Process
The heart of the product lies in its circuit board. Highly skilled technicians first carefully place surface mount devices (SMDs), such as microcontrollers, transistors, and capacitors, onto the printed circuit board (PCB) using precision pick-and-place machines. Afterward, through-wave soldering is employed to create reliable electrical connections. This process ensures the integrity of the complex circuitry responsible for power conversion, control, and communication.
| TYPE |
GES48100M200-500
|
GES48120M220-500
|
|---|---|---|
| INVERTER | ||
| Rated Output Power | 10000W | 12000W |
| Max.Peak Power | 15000W | 18000W |
| Rated Output Voltage | 120/240Vac(L1/L2/N/PE split phase) | |
| Rated AC Frequency | 50/60Hz | |
| BATTERY | ||
| Battery Type | Li-ion/Lead-Acid | |
| Rated Battery Voltage | 48V | |
| Max.MPPT Charging Current | 200A | |
| PV INPUT | ||
| Num. of MPPT Trackers | 2 | |
| Max.PV Array Power | 12000W | |
| Max.Input Current | 22/22A | |
| MPPT Voltage Range |
90Vdc~450Vdc
|
|
| EFFICIENCY | ||
| MPPT Tracking Efficiency | 99% | |
| Max. Battery Inverter Efficiency | 92% | |
| GENERAL | ||
| Dimensions |
620*450*132
|
|
| Operating Temperature Range | -10~55℃,>45°C derated | |
| Embedded interfaces | RS485/USB/ Dry contact/(Wi-Fi/GPRS) | |
