Optimized Night Power Mode
Even at night, the product doesn't stop working for you. It features an optimized night power mode that intelligently manages any residual energy in the battery. It can supply minimal power to essential low-power devices like security cameras or clocks, conserving battery life while ensuring basic functionality. This smart mode avoids unnecessary battery drain and prepares the system for efficient operation when daylight returns and solar power generation resumes.
Strong Anti-Interference Capability
In an electrically noisy environment filled with various electronic devices and appliances, the inverter stands strong. It has excellent anti-interference capabilities, shielding itself from electromagnetic interference emitted by neighboring equipment. This ensures stable operation and accurate power conversion, preventing disruptions or errors caused by external electrical noise, and maintaining the integrity of your power supply.
Automated Production Line Assembly
The manufacturing process begins with an automated production line where robotic arms precisely pick and place components onto printed circuit boards (PCBs). This high-precision assembly minimizes human error, ensuring consistent quality across each unit. The PCBs then pass through automated soldering stations, where solder paste is applied and components are reflow soldered, creating reliable electrical connections.
| TYPE |
SPI4836M80-300
|
SPI4865M80-300
|
|---|---|---|
| INVERTER | ||
| Rated Output Power | 3600W | 6500W |
| Max.Peak Power | 7200W | 12000W |
| Rated Output Voltage |
120Vac
|
|
| Rated AC Frequency | 50/60Hz | |
| BATTERY | ||
| Battery Type | Li-ion/Lead-Acid | |
| Rated Battery Voltage | 48V | |
| Max.MPPT Charging Current | 200A | |
| PV INPUT | ||
| Max.PV Array Power | 4000W | 4500w*2 |
| Max.Input Current | 22A | 22A*2 |
| MPPT Voltage Range |
90-260Vdc
|
|
| EFFICIENCY | ||
| MPPT Tracking Efficiency | 99% | |
| Max. Battery Inverter Efficiency | 92% | |
| GENERAL | ||
| Dimensions |
415*280*100
|
540*350*120
|
| Operating Temperature Range | -15~55℃ | |
| COMMUNICATION | ||
| Embedded interfaces | RS485/USB/ Dry contact | |
| External Modules (Optional) | Wi-Fi/GPRS | |
