Dual MPPT Trackers (99.9% Efficiency): Equipped with 2 independent MPPT trackers to optimize energy capture from 2 separate PV strings. Adapts to partial shading, mixed orientations, or varying sunlight, boosting daily solar yield by 8–12% compared to single-MPPT models.
Seamless Grid Synchronization: Automatically syncs with single-phase (230V) or three-phase (400V) grids (50Hz/60Hz), enabling bi-directional energy flow-exports excess solar power to the grid for net metering credits while aligning with utility standards.
Pure Sine Wave Output: Generates clean AC power with total harmonic distortion (THD) <3%, protecting sensitive electronics (home offices, commercial equipment) and ensuring compliance with grid codes (IEEE 519, IEC 61000).
Wide PV Input Range: Each MPPT supports 100V–550V DC input, compatible with diverse solar panel configurations (series/parallel setups). Accommodates up to 9.6kW total PV input, allowing 20% oversizing to maximize energy capture during peak sunlight.
Rapid Grid Response: Adjusts to grid voltage/frequency fluctuations in milliseconds, maintaining stable operation even during utility grid variations. Ensures uninterrupted energy export without tripping.
Advanced Grid Protection: Built-in safeguards against overvoltage, overcurrent, frequency deviations, and islanding (complies with UL 1741, VDE). Automatically shuts down during grid outages to protect utility workers and equipment.
|
Model |
S6-EH3P10K02-NV-YD-L |
Battery type |
Lead acid or lithium battery |
|
Mains mode |
Max. charge current | 220A | |
|
Nominal input voltage |
380/400V |
Charge voltage range |
40 –60Vdc |
|
Frequency |
50Hz/60Hz (Auto detection) |
Solar charge |
|
|
Max. efficiency |
97.6% |
PV operate voltage range |
200Vdc~800Vdc |
|
Inverter mode |
MPPT voltage range | 200Vdc~800Vdc | |
|
Output voltage waveform |
Pure sine wave |
Max. PV input power/current |
16000W/40A |
|
Nominal output power(VA)/(W) |
10000W |
Charge current range |
220A |
|
Nominal output voltage (Vac) |
380/400V |
Certification |
|
|
Peak power |
20000VA |
EMC certification level |
NRS 097-2-1, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530 PEA\MEA, IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-3 |
|
Protection |
IP66 |
Operate temperature range |
-40 to +60℃ |
|
Battery voltage range |
40.0Vdc~60Vdc |
communicate |
RS485/CAN |
|
Mains charge |
Humidity range | 5% to 95%(Conformal coating protection) | |
Comparison Of Protection Levels
IP66 VS IP65
Dustproofcapability: Dustproof capability:
Completely dust-proof, no particles enter Completely dust-proof, no particles enter
Waterproofcapability: Waterproofcapability:
Protect against strong water column impact, twice Protect against low pressure water column impact
the water proof capacity of IPx5
Absolute advantage:
Dust-proof , IP66 can withstand strong currents, use is wider inthe environment of strong
convective weather like typhoon, rainstorm frequent have stronger adapt ability
