5kw Solar Energy System Off Grid With Efficient Panels

High-Efficiency Panels for Maximum Off-Grid Harvest
Premium Monocrystalline Panels: Equipped with 14–16 high-efficiency monocrystalline solar panels (300–370W each, 23–25% conversion rate)—among the most efficient on the market. These panels generate 15–25kWh/day in sunny conditions, even in low light (cloudy days, early mornings) or partial shading, outperforming standard panels by 15–20% in energy capture.
Anti-Reflective & Durable: Panels feature tempered glass with anti-reflective coating to absorb more sunlight and resist scratches, while corrosion-resistant aluminum frames withstand extreme weather (hail, wind speeds up to 120mph) and temperature swings (-40°F to 185°F)—critical for remote off-grid locations.

Products Description

1~30KW Solar Energy Systems

Powerful 5kW Output for Off-Grid Living

5kW Continuous AC Power: Delivers 5kW of stable AC power (surge capacity up to 10kW) to run off-grid essentials and more: refrigerators, freezers, well pumps, small air conditioners, electric stoves, and even power tools. Perfect for 2–3 bedroom remote cabins or off-grid homes with moderate energy needs (15–20kWh/day).

Pure Sine Wave Inverter: Converts DC power (from panels and batteries) to clean AC power with <3% total harmonic distortion (THD), safely powering sensitive electronics like laptops, medical devices (e.g., CPAP machines), and smart appliances without performance issues.

Ample Battery Storage for 24/7 Independence

20–30kWh LiFePO4 Battery Bank: Integrates a high-capacity lithium-iron-phosphate battery with 20–30kWh storage, designed for 3,000+ charge cycles (10+ year lifespan). With 80% depth of discharge (DoD), it provides 16–24kWh of usable energy-enough to power an off-grid home through 1–2 nights or during extended cloudy periods.

Smart BMS Optimization: A built-in Battery Management System (BMS) regulates charging/discharging rates, prevents overcharging/over-discharging, and balances cell voltage, extending battery life by 20% and ensuring reliable performance in all seasons.

product-1000-451

Years Solar Panel

Years PV Racking

Years Battery

Years Inverter

One-stop service, including free system design, installation manual & instructions and videos, after-sales accessories, online technical support, etc.

Home Use Hybrid Solar Energy Storage System
Item	Mecc-3kw	Mecc-5kw	Mecc-8kw	Mecc-10kw	Mecc-15kw	Mecc-20kw	Mecc-30kw
Mono Solar Panel 550W	6pcs	10pcs	16pcs	20pcs	30pcs	40pcs	60pcs
Hybrid Inverter/ Off-grid Inverter	110V/220V 220V 380V 50 - 60HZ Selectable 3KW 5KW 8KW 10kw 12kw 15kw 20kw 30kw Selectable
Panel Bracket	Ground mounts, roof mounts, a wide range of PV mounts to choose from
PV Combiner box	N in 1 out
MC4 Connector	4pairs		8pairs			16pairs
PV Cable	4M² 50M			4M² 100M
lithium Battery (power wall) (Can be added) (5KWH)	Lithium Battery Packs BMS/MBMS/EMS Protection; GEL/OPzV Batteries Optional
Cloud Monitoring System	1pcs
