Products Description
High System Voltage Compatibility
Thanks to the excellent insulation properties of glass, the double-glass solar panel demonstrates high system voltage compatibility. It can meet the requirements of higher system voltages, which is beneficial in large-scale photovoltaic power generation projects. By allowing for a reduction in the number of panels connected in series, it simplifies the system design, reduces costs, and improves the stability and safety of the entire power generation system. Some models can support a maximum system voltage of up to 1500V, providing a more efficient solution for medium and high-voltage photovoltaic power plants.
Low Light Performance
Even in low light conditions such as cloudy days or early morning and late afternoon, this solar panel can still generate a certain amount of electricity. Its advanced cell technology and design enable it to capture and convert diffused light more efficiently. Although the power output may be lower than that in full sunlight, it can still contribute to continuous power supply, making it suitable for applications where a stable power source is required throughout the day, such as off-grid power systems or hybrid power generation setups.
Products parameters
|
Max Power Pmax(W) |
570 | 575 | 580 | 585 | 590 | ||||
|
Max Power Voltage(Vmp/V) |
43.58 | 43.73 | 43.88 | 44.02 | 44.17 | ||||
|
Max Power Current(Imp/A) |
13.08 | 13.15 | 13.22 | 13.29 | 13.36 | ||||
|
Open Circuit Voltage(Voc/V) |
52.1 | 52.3 | 52.5 | 52.7 | 52.9 | ||||
|
Short Circuit Current(Isc/A) |
13.83 | 13.89 | 13.95 | 14.01 | 14.07 | ||||
|
Module Efficiency(%) |
22.07 | 22.26 | 22.45 | 22.65 | 22.84 | ||||
|
Power Tolerance(W) |
0 ~ + 3 %
|
||||||||
|
Operating Temperature
|
-40 °C ~ +85 °C
|
||||||||
|
Max Series Fuse Rating
|
30 A
|
||||||||
Products Overview
| Product Specification | |
| Module Size |
2278×1134×30 mm
|
| Weight | 31kg |
| Cell Type |
N- type Mono-crystalline
|
| Junction Box | IP68 Rated |
Factory
Sustainable Manufacturing Practices
We are committed to sustainable manufacturing in our solar panel factory. We strive to minimize our environmental impact by optimizing energy consumption during production. Our factory is equipped with energy-efficient machinery and utilizes renewable energy sources, such as solar power generated by our own rooftop panels, to power a portion of our operations. Additionally, we have implemented waste reduction and recycling programs to ensure that materials like silicon scraps and packaging are properly recycled or reused, contributing to a more sustainable future.
Efficient Supply Chain Management
Efficient supply chain management is crucial in our solar panel factory. We have established strong partnerships with reliable suppliers of raw materials, ensuring a steady and high-quality supply of silicon, glass, and other components. Our logistics team coordinates the seamless transportation of these materials to the factory and the distribution of finished solar panels to customers worldwide. By optimizing inventory levels and streamlining the supply chain, we are able to reduce production costs and meet customer demands in a timely manner.
FAQ
Are these solar panels more expensive than single-glass ones?
Generally, these solar panels tend to have a higher initial cost due to the additional glass layer and the associated manufacturing processes. However, their longer lifespan, better durability, and potentially higher energy generation in certain conditions (such as bifacial power generation) can make them more cost-effective in the long run. The price difference also depends on factors like brand, quality, and market demand.
Can I connect multiple solar panels in series or parallel?
Yes, you can. When connecting in series, the voltages add up. For example, if each panel has a voltage of 40V and you connect two in series, the total voltage becomes 80V, while the current remains the same. When connecting in parallel, the currents add up. So two panels with a current of 10A in parallel will give a total current of 20A, and the voltage stays the same. But it's important to ensure that the panels are of the same type, rating, and have proper connection methods to avoid issues like overcharging or imbalanced charging.
