Power Output & Efficiency: At 1200W, this system typically consists of 3–4 monocrystalline panels (300–400W each) with 22–23% conversion efficiency-maximizing energy capture even in urban environments with partial sunlight. Under standard conditions, it generates 4–6kWh daily (enough to power LED lights, laptops, a small fridge, and a TV), reducing grid dependency by 30–50% for a small apartment.
Space-Saving Design:
Compact Panels: Each panel measures ~165 × 105 × 3cm (length × width × thickness) and weighs 13–15kg-slim enough to fit on standard balconies (including narrow ones) without blocking access or views. The sleek, low-profile build (matte black or silver frames) blends with railings, outdoor furniture, or urban decor, avoiding a bulky appearance.
Flexible Mounting: Non-drilling, adjustable brackets (15–30° tilt) attach securely to railings or walls, optimizing sun exposure (south/north-facing) while keeping installation renter-friendly (no permanent modifications).
Integrated Micro Inverters:
Each panel pairs with a dedicated 300–400W micro inverter, converting DC to AC at 96–97% efficiency. Unlike string inverters, this "per-panel" setup eliminates power loss from shading (common in cities with tall buildings), ensuring consistent output even if one panel is shaded.
Grid-tie capable (where net metering applies), allowing excess energy to be exported to the utility grid for credits, further reducing bills.
User-Friendly Installation & Safety:
DIY Setup: Panels clip into brackets, and micro inverters plug into standard 110V/220V outlets-no electrician needed. Total installation takes 30–60 minutes.
Weather Resistance: Panels and inverters are IP65-rated to withstand rain, wind (up to 100km/h), and temperatures from -10°C to 50°C, with UV-resistant materials to prevent fading.
Safety Features: Overcurrent/overvoltage protection, automatic grid outage shutdown, and fire-retardant casings meet residential safety standards.
|
Model
|
EVT600
|
|
Input
|
|
|
Input Power Range
|
180-550W*2
|
|
Operating Range
|
16-60V
|
|
Input Current
|
14A*2 |
|
Output Data
|
|
|
Normal Voltage
|
220/230V
|
|
Frequency
|
50/60Hz
|
|
Power
|
600W |
| Others | |
|
Efficiency
|
96.8%
|
|
Communication
|
PLCC
|
|
Warranty
|
15 years |
|
IP
|
IP67
|
|
Temperature
|
- 40 to 65℃
|
|
Weight
|
4kg
|
Factory
Employee Welfare and Amenities
We care about the well-being of our employees. The factory provides a range of amenities, including a cafeteria offering healthy and diverse food options, a rest area for employees to relax during breaks, and a fitness center to promote a healthy lifestyle. These amenities contribute to a positive work environment and increased employee satisfaction.
FAQ
Can I install the kit on a balcony with a skylight?
If the skylight does not cause significant shading on the solar panels, it can be installed. However, the skylight's position and the sunlight it allows through need to be considered. The panels may need to be positioned to avoid interfering with the skylight's function and to optimize their own sunlight absorption. It may also be necessary to adjust the panel tilt and orientation.
What is the role of the mica capacitor in the system?
Mica capacitors are used in the set for their high stability and reliability. They are often used in applications where precise capacitance values and good temperature stability are required. For example, in some filter circuits or timing circuits within the inverter or other components, mica capacitors can help to ensure accurate and stable operation.
