Products Description
Power & Efficiency with Microinverter Advantage: The system pairs two 400W monocrystalline solar panels (totaling 800W) with a compact 800W microinverter, a key upgrade over traditional string inverters. Each panel boasts 21–23% conversion efficiency, while the microinverter optimizes power output at the panel level-minimizing losses from partial shading (common in urban canyons) or panel mismatch. This setup generates 3.2–4.8kWh daily in sunny conditions, enough to power LED lights, charge laptops/phones, run a small fridge, microwave, or air purifier, cutting grid reliance for daily essentials.
Balcony-Specific Installation & Safety: Designed for renter-friendly setup, the system includes adjustable rail-mount brackets or wall hooks that attach securely to balcony railings or walls-no drilling into structural surfaces. Each panel (≈170×110×3cm, ~13kg) is slim and lightweight, with weather-resistant casings (IP65-rated) to withstand rain, dust, and moderate wind. The microinverter adds built-in protections: overcurrent, short-circuit, and voltage surge safeguards prevent electrical hazards, while its low-profile design integrates seamlessly with the panels, avoiding clutter.
Plug-and-Play Functionality & Smart Monitoring: The microinverter converts DC solar power to AC directly at the panel, eliminating high-voltage DC wiring and enabling direct connection to standard household outlets. Many models include USB ports for device charging, with no need for professional installation. Advanced systems feature Wi-Fi connectivity, letting users track real-time energy production, daily yields, and savings via a smartphone app-empowering informed energy management. Optional compatibility with small batteries (500Wh–1kWh) stores excess energy for evening use, ensuring power after sunset.
Urban Adaptability & Scalability: The panels fit typical balcony dimensions (170cm length works with most railings) and feature adjustable angles (0–30°) to optimize sunlight capture, even in shaded urban areas. The microinverter's grid compatibility allows surplus energy to be fed back (where net metering applies) for credits. Its modular design lets users start with one 400W panel and expand to 800W later, adapting to growing needs.
|
Model
|
EVT800
|
|
Input
|
|
|
Input Power Range
|
180-550W*2
|
|
Operating Range
|
16-60V
|
|
Input Current
|
14A*2 |
|
Output Data
|
|
|
Normal Voltage
|
220/230V
|
|
Frequency
|
50/60Hz
|
|
Power
|
800W |
| Others | |
|
Efficiency
|
97%
|
|
Communication
|
PLCC
|
|
Warranty
|
15 years |
|
IP
|
IP67
|
|
Temperature
|
- 40 to 65℃
|
|
Weight
|
4.1kg
|
Factory
Future Expansion and Growth Strategies
The factory has ambitious plans for future expansion and growth. We are constantly exploring new markets and applications for our products. This includes research into integrating our systems with smart home technologies and energy storage solutions for enhanced functionality. We also plan to invest in additional production capacity and R&D facilities to meet the growing global demand for clean and sustainable energy solutions. Strategic partnerships and acquisitions are being considered to strengthen our position in the market and accelerate our growth trajectory.
FAQ
Can I install it on a balcony with a glass railing?
Installing on a balcony with a glass railing is possible. The mounting brackets can be attached to the balcony structure rather than the railing itself. However, the glass railing may affect the sunlight reflection and the overall aesthetics of the installation. Careful consideration of the panel placement and orientation is needed to optimize sunlight capture and minimize visual impact.
What is the role of the resistor in the set?
Resistors in the kit are used for various purposes. They can limit the current in a circuit, provide a voltage drop, or be used in combination with other components for signal conditioning. For example, in some circuits within the inverter or the charge controller, resistors help to set proper operating voltages and currents, ensuring the correct functioning of it.
